Crane Hook Block

Send Message Inquiry Now
Crane Hook Block
Crane Hook Block
Crane Hook Block
Crane Hook Block
Crane Hook Block
Crane Hook Block
Crane Hook Block
Crane Hook Block
Crane Hook Block
Crane Hook Block
Work Load Size(mm) Wire Rope
A B H φD Dia.(mm)
3.2T 575 341 426 300 11-14
5T 715 341 426 350 11-14
10T 1080 370 526 250 11-14
16T 1330 500 660 310 14-20
20T 1415 515 653 500 16-20
32T 1740 620 780 610 18-22
50T 1965 830 815 610 20-22
75T 2335 970 1012 500 26-32
100T 3130 1360 1162 800 28-34
200T 3548 1617 1090 900 30-38

Overview

Crane hook block is a common device for grabbing and lifting loads used by a hoist or crane. The lifting hook is usually equipped with safety latch to ensure the wire rope sling, chain or rope in the proper place of hook and ensure the safety. With one or more built-in pulleys, the crane hook group can amplify the lifting force.

Advantages of Crane Hook Block：

1、Easy to handle hook blocks are closed and rotate freely 360 degrees.

2、Hooks are supported on anti-friction lifetime lubricated bearings and are made from quenched and tempered 34CrMoV steel according to DIN17200.

3、Each Hook is fitted with a spring-loaded sturdy safety latch, ensuring that slings cannot accidentally release from the hook. Hook forging is ergonomically designed.

Application

Due to the characteristics of simple manufacture and strong usability, crane hook group is used widely to handle materials. As the most widely used loads handling devices, crane hook groups are usually used with hoist or crane machinery for handling materials in various applications in different industries.
